Parameters of heating part

Number of heating zones

Up 5/Down 5

Length of heating zone

2960mm

Exhaust air volume

Above 10m3/min

Transportation parameters

Maximum width of PCB board

300mm to 350 optional

Transportation direction

Right left (left and right optional, subject to the provisions in the customer's purchase order)

Height of conveyor belt

920±20mm

PCB board transportation mode

Net drive

Belt speed

0~1800mm/Min

Parameters of control part

Power Supply

three Ψ 380V  50/60HZ

Starting power

16KW

Power consumption under normal operation

8KW

Power distribution

The upper five temperature zones are all 2KW, and the lower five temperature zones are all 1KW

Heating time

Approx.20~30min

Temperature control range

Room temperature - 300 ℃

Temperature control mode

PID closed-loop control, SSR drive

Set parameter storage

Multiple setting parameters can be saved

Abnormal alarm

Abnormal temperature (ultra-high or ultra-low temperature after constant temperature) alarm

Signal beacon

Three color light yellow temperature rise. Green - Constant temperature. Red Abnormal

Body parameters

Overall dimensions

See the outline drawing on the previous page

weight

500KG

colour

Computer gray (subject to the color specified in the technical agreement)
